Description

CEPLATTYN KG

CEPLATTYN KG 10 HMF-2500 is a highly specialized, sprayable adhesive lubricant designed specifically for open gear drives operating under extreme conditions. This product combines a high-viscosity base oil, aluminum-complex soap thickener, and an advanced additive package (free from heavy metals and chlorine) to deliver exceptional performance in heavy-duty industrial applications.

Key Features:

1. Temperature Range: Operates effectively between +5°C to +140°C (+40°F to +280°F).
2. Anti-Wear Properties: Excellent protection against wear, ensuring durability and longevity of gear components.
3. Adhesion and Corrosion Protection: Outstanding adhesive qualities provide lasting lubrication while offering superior protection against corrosion.
4. Resistance to Compression: Withstands extreme pressure and load conditions, reducing damage from tribocorrosion.
5. Water Resistance: Maintains performance in wet environments.
6. Cushioning Effect: Provides shock load absorption, reducing operational vibrations and noise.
7. Stability of Lubricating Film: Ensures consistent lubrication even under high temperatures and loads.

Product Description:

CEPLATTYN KG 10 HMF-2500 is formulated with:

• High-viscosity base oil for superior cushioning.
• Aluminum-complex soap thickener for structural stability.
• Colloidal graphite and adhesion additives, ensuring a robust lubricating film.

It does not contain solvents, making it safer and more environmentally friendly compared to other lubricants.

Applications:

This lubricant is ideal for:

• Open Gear Drives: Particularly those experiencing extreme load peaks and shock loads.
• Predamaged Tooth Flanks: Provides protection and operational reliability under critical conditions.
• Heavy-Duty Environments: Suitable for industrial settings requiring high durability and thermal stability.

Application Guidelines:

• Spraying Systems: Use standard commercial spraying equipment for application.
• Cold Weather Precaution: For temperatures below +5°C, preheating may be necessary to ensure proper sprayability.

Technical Specifications:

• Base Oil Viscosity: 2,500 mm²/s at 40°C; 14,000 SUS at 100°F
• Thickener Type: Aluminum-complex
• NLGI Grade: 0-00
• Dropping Point: 180°C
• Four Ball Test Welding Load: 6,500/7,000 N
• TIMKEN OK-Load: 45 lbs
• FZG A/2.8/50 Damage Load Step: >12
• Wear Specific Value: <0.2 mg/kWh

This product is a reliable solution for industries requiring top-tier performance under harsh operational conditions. Users should verify suitability for specific applications and follow all operational and safety guidelines.
