CEPLATTYN RN
Sprayable running-in lubricant for open gears
Performance Features
• temperature range: -10 / +140°C
• reduces surface roughness to a minimum
• improves quality of tooth flanks
• extends life time of the gear
• free of chlorine and heavy metals
Description
CEPLATTYN RN is based on a mineral base oil and an aluminium-complex soap as thickener. It is highly graphited,
adhesive and sprayable. CEPLATTYN RN does neither contain bitumen nor solvent. In addition it is free of heavy
metals and chlorine. CEPLATTYN RN together with CEPLATTYN 300 and CEPLATTYN KG 10 HMF represent the
FUCHS LUBRITECH multi-phase system.
Field of application
CEPLATTYN RN can be applied to single and double pinion drives of any kind of tube mills and kilns, e.g. in cement
works, fertilizer plants, combustion and compost units. CEPLATTYN RN is applied to gear drives with high
performance. Furthermore it is used when running under critical operating conditions, when having big tooth widths
or when running with high speeds.
Method of application
CEPLATTYN RN is applied via automatic spraying systems: Spraying should be effected permanently and with highest possible quantity. Running-in of gears should start only after best alignment of the gear. Primary lubrication
of tooth flanks should be effected with CEPLATTYN 300, according to our INSTRUCTIONS FOR RUNNING IN.
Technical Data: CEPLATTYN RN
Characteristics Value Unit Test Method
Colour black
Temperature range -10 / +140 ° C LLS 134
Thickener AL-X
Base oil viscosity [40°C] 460 mm²/s DIN 51562-1
NLGI grade 00 DIN 51818
Dropping point 200 ° C DIN ISO 2176
Four Ball Test welding load 5000/5500 N DIN 51350-4
FZG A/2.8/50 – damage load step >12 DIN ISO 14635-3 [LLS]
Behaviour against nonferrous metals and seals neutral LLS
LLS = LUBRITECH Laboratory Specification
Typical for current production. Variations in these characteristics may occur.
As far as we know this information reflects the current state of knowledge and our research. It cannot, however, be taken as
an assurance about the properties nor as a guarantee of the suitability of the product for the individual case in point. Before
using our products the purchaser must, therefore, check their suitability and be satisfied that the output will be satisfactory.
Please be aware that our products must not be used for applications in nuclear primary circuits or on-board aerospace
systems. Our products undergo continuous improvement. We therefore retain the right to change our product program, the
products, and their manufacturing processes as well as all details of our product information sheets at any time and without
prior announcement, unless otherwise provided in customer-specific agreements. With the publication of this product
information sheet, all previous editions cease to be valid.
We are specialized in developing products for extreme tribological problems in cooperation with end users.
FUCHS LUBRITECH provides service and individual advice. Please contact us!
E-Mail: flt.info@fuchs.com
Description
What Is CEPLATTYN RN?
CEPLATTYN RN is a premium lubricant designed for heavy-duty industrial use. It ensures optimal performance and protection for machinery under extreme conditions.
Key Benefits of CEPLATTYN RN
- Superior Adhesion: Its advanced formulation ensures long-lasting adherence to surfaces.
- High Load Capacity: Protects components from wear even under intense pressure.
- Corrosion Resistance: Shields machinery from rust and environmental damage.
- Wide Temperature Range: Performs efficiently in both high and low temperatures.
Applications of CEPLATTYN RN
- Mining Equipment: Ideal for lubricating gears, bearings, and chains in rugged environments.
- Cement Plants: Ensures smooth operation of rotary kilns and mills.
- Steel Industry: Protects machinery in high-temperature and high-load conditions.
- Wind Turbines: Reduces wear on gearboxes and improves energy efficiency.
How to Apply CEPLATTYN RN
- Clean the Surface: Remove any dirt or old lubricant residues.
- Apply Evenly: Use a brush or automatic applicator for consistent coverage.
- Monitor Usage: Regularly check the lubricant levels to maintain optimal performance.
Why Choose CEPLATTYN RN Over Other Lubricants?
CEPLATTYN RN stands out for its reliability and performance. Its unique composition reduces maintenance costs and extends the life of machinery.
Environmental Advantages of CEPLATTYN RN
- Eco-Friendly Formula: Free from harmful additives, ensuring minimal environmental impact.
- Reduced Waste: Its long-lasting properties mean less frequent application.
Maintenance Tips for Optimal Results
- Store Properly: Keep in a cool, dry place to maintain its properties.
- Schedule Inspections: Check machinery regularly for signs of wear.
- Follow Manufacturer Guidelines: Ensure proper use and avoid over-application.
Conclusion
CEPLATTYN RN is the ultimate solution for industrial lubrication needs. Its advanced features, versatility, and reliability make it the go-to choice for professionals. Enhance your machinery’s performance and longevity with this exceptional product.
