Description

LH Distributor in Chandigarh & Jammu & Kashmir

Alloy Basis

The electrode is made of a blend of Fe, Cr, Ni, Mo, offering a robust solution for welding applications that require high tensile strength and resistance to heat and chemical corrosion. LH Distributor in Chandigarh & Jammu & Kashmir

Properties

This all-position electrode provides a 25Cr/12Ni deposit, delivering exceptional performance in various welding tasks. It offers high tensile strength, outstanding resistance to chemical corrosion, and heat. The electrode operates smoothly, providing excellent slag detachability with minimal spatter. The weld bead produced is smooth, shining, and uniform, achieving radiographic quality that ensures reliable results.

Technical Data

• UTS (Ultimate Tensile Strength): 57-67 kgf/mm²
• Elongation: 30-45%

Typical Applications

This electrode is specially developed for multi-pass, crack-free buildup of all steels, particularly in mining machinery components and bearing areas. It also excels in cladding carbon steels to improve wear and corrosion resistance. Additional applications include:

• Multi-pass Deposits: Ideal for steady deposition at lower currents, ensuring consistent and high-quality results.
• Joining Mn Steel to Carbon Steel: Provides effective joining of manganese steel to carbon steels for a strong, durable weld.
• Mining Machinery Components & Bearing Areas: Perfect for repairing and building up mining machinery parts, enhancing durability and resistance to wear and tear.

Procedure

To achieve the best results, clean the weld area thoroughly and remove any fatigued or cracked metal. For thicker materials, use a bevel with a 60-90° included angle U. A stringer bead technique with the shortest possible arc length is recommended for a precise and consistent finish. For optimal performance, use DCRP (DC +), which ensures a good ripple and clean finish.

Welding Current

The electrode is suitable for both AC and DC (+) power sources. It is available in the following sizes and current ranges:

• Size (∅ mm) / Length: 3.2×350, 4.0×350, 5.0×350
• Current Range (amps):
  • 3.2×350: 90-100 amps
  • 4.0×350: 100-135 amps
  • 5.0×350: 140-185 amps

Why Choose Us as Your LH Distributor in Chandigarh & Jammu & Kashmir?

As a trusted LH Distributor in Chandigarh & Jammu & Kashmir, we provide high-quality electrodes that meet the demands of various welding applications, from mining machinery to carbon steel cladding. With reliable delivery and expert guidance, we are your go-to partner for all welding needs.

Contact us today for the best welding solutions and exceptional service in Chandigarh & Jammu & Kashmir! avighnaengineering
